White
IP67
Galvanised
Wall
Carbon Steel
UL Listed
Low Smoke & Zero Halogen Pvc coated flexible conduit
With BSI TEST, IP 67 TEST AND Firing test report, for high qulality and dangerous projects use
Quick Detail:
Size:3/8''(12mm) to 4''(100mm)
Color: black or grey
Material: inside -galvanized steel, outside : pvc
Pvc flexible hose or plastic flexible conduit
Description:
Flexible metal conduits for general purpose applications and installations in close quarters that require added
flexibility made from high-grade, hot dipped,galvanized low carbon steel.
Continuous interlocking metal strip design enhances flexibility a nd intergrity
Interior surface allows for easy wire fishing
3-hour through-penetration fire systems
Brand name: Ranlic
Applications:
Widely used for general electrical wiring where flexibility and mechanical protection are required.
Connect fm conduit to junction box
Specifications:
UL LISTED AND BSI CERTIFIED Liquid Tight Flexible Conduit 1/2"(12mm) to 4" (113.20mm)
General: For protectiong the electrical wire, all the steel coil thickness exceeding 3.5mm to assure 190 ponds pressure, avoid the heavy item press flexible conduit abnormally. galvanized thickness eceeding 40 micrometer anti rust,Inside with the cotton wire to make the pvc flat and wiring easily.
Features: 1) Hot-dip/electro-gal.steel coil material work temp.-25 to 350 degree 2) All package meters available 15meter,25meter,30meter and 100feet. 3) The PVC part durable and reach to IP6 anti fire
Size & details:
Why Choose Ranlic Flexible Conduit
We are sending samples free of charges
All testing and the production in the our factory to assure the quality
When start buying our products,if destination markets growing fastly ranlic will pay advertisment in customer's market to help our customer publishing our brand. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Competitive Advantage:
Quick delivery: 10 days for one 40ft container
Compititve price
Gray Color With Cotton Wire Liquid Tight Flexible Conduit 1/2"(12mm) to 4" (113.20mm)
General:
For protectiong the electrical wire, all the steel coil thickness exceeding 3.5mm to assure 190 ponds pressure, avoid the heavy item press flexible conduit abnormally. galvanized thickness eceeding 40 micrometer anti rust,Inside with the cotton wire to make the pvc flat and wiring easily.
Features:
1) Hot-dip/electro-gal.steel coil material work temp.-25 to 350 degree
2) All package meters available 15meter,25meter,30meter and 100feet.
3) The PVC part durable and reach to IP6 anti fire
Size & details:
| INSIDE DIA. | OUTSIDE DIA. | ITEM | PITCH | GAL.COIL | MIN.BEND | STANDARD | ||
| IN. | MM | MM | CODE | MM | THICKNESS | RADIUS | PACKAGE METERS | |
| 3/8" | 12mm | 17.50mm | RL-F80 | 4.70mm | 0.22mm | 60 Degree | 100 Meters | |
| 1/2" | 15mm | 20.80mm | RL-F81 | 5.70mm | 0.22mm | 80 Degree | 50 Meters | |
| 3/4" | 20mm | 26.20mm | RL-F82 | 6.40mm | 0.22mm | 100 Degree | 30 Meters | |
| 1" | 25mm | 32.70mm | RL-F83 | 8.70mm | 0.22mm | 150 Degree | 30 Meters | |
| 1-1/4" | 32mm | 41.40mm | RL-F84 | 10.50mm | 0.35mm | 180 Degree | 15 Meters | |
| 1-1/2" | 38mm | 47.40mm | RL-F85 | 11.40mm | 0.35mm | 200 Degree | 15 Meters | |
| 2" | 50mm | 59.40mm | RL-F86 | 11.40mm | 0.38mm | 250 Degree | 10 Meters | |
| 2-1/2" | 63mm | 72.10mm | RL-F87 | 14.20mm | 0.45mm | 300 Degree | 10 Meters | |
| 3" | 75mm | 87.90mm | RL-F88 | 14.20mm | 0.45mm | 450 Degree | 5 Meters | |
| 3-1/2" | 83mm | 98.50mm | RL-F89 | 14.20mm | 0.45mm | 500 Degree | 5 Meters | |
| 4" | 100mm | 113.20mm | RL-F90 | 14.20mm | 0.45mm | 600 Degree | 5 Meters | |
Why Choose Ranlic Flexible Conduit
We are sending samples free of charges
All testing and the production in the our factory to assure the quality
When start buying our products,if destination markets growing fastly ranlic
will pay advertisment in customer's market to help our customer publishing
our brand.
Low Smoke & Zero Halogen Pvc coated flexible conduit
With BSI TEST, IP 67 TEST AND Firing test report, for high qulality and dangerous projects use
Quick Detail:
Size:3/8''(12mm) to 4''(100mm)
Color: black or grey
Material: inside -galvanized steel, outside : pvc
Pvc flexible hose or plastic flexible conduit
Description:
Flexible metal conduits for general purpose applications and installations in close quarters that require added
flexibility made from high-grade, hot dipped,galvanized low carbon steel.
Continuous interlocking metal strip design enhances flexibility a nd intergrity
Interior surface allows for easy wire fishing
3-hour through-penetration fire systems
Brand name: Ranlic
Applications:
Widely used for general electrical wiring where flexibility and mechanical protection are required.
Connect fm conduit to junction box
Specifications:
UL LISTED AND BSI CERTIFIED Liquid Tight Flexible Conduit 1/2"(12mm) to 4" (113.20mm)
General: For protectiong the electrical wire, all the steel coil thickness exceeding 3.5mm to assure 190 ponds pressure, avoid the heavy item press flexible conduit abnormally. galvanized thickness eceeding 40 micrometer anti rust,Inside with the cotton wire to make the pvc flat and wiring easily.
Features: 1) Hot-dip/electro-gal.steel coil material work temp.-25 to 350 degree 2) All package meters available 15meter,25meter,30meter and 100feet. 3) The PVC part durable and reach to IP6 anti fire
Size & details:
Why Choose Ranlic Flexible Conduit
We are sending samples free of charges
All testing and the production in the our factory to assure the quality
When start buying our products,if destination markets growing fastly ranlic will pay advertisment in customer's market to help our customer publishing our brand. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Competitive Advantage:
Quick delivery: 10 days for one 40ft container
Compititve price
Gray Color With Cotton Wire Liquid Tight Flexible Conduit 1/2"(12mm) to 4" (113.20mm)
General:
For protectiong the electrical wire, all the steel coil thickness exceeding 3.5mm to assure 190 ponds pressure, avoid the heavy item press flexible conduit abnormally. galvanized thickness eceeding 40 micrometer anti rust,Inside with the cotton wire to make the pvc flat and wiring easily.
Features:
1) Hot-dip/electro-gal.steel coil material work temp.-25 to 350 degree
2) All package meters available 15meter,25meter,30meter and 100feet.
3) The PVC part durable and reach to IP6 anti fire
Size & details:
| INSIDE DIA. | OUTSIDE DIA. | ITEM | PITCH | GAL.COIL | MIN.BEND | STANDARD | ||
| IN. | MM | MM | CODE | MM | THICKNESS | RADIUS | PACKAGE METERS | |
| 3/8" | 12mm | 17.50mm | RL-F80 | 4.70mm | 0.22mm | 60 Degree | 100 Meters | |
| 1/2" | 15mm | 20.80mm | RL-F81 | 5.70mm | 0.22mm | 80 Degree | 50 Meters | |
| 3/4" | 20mm | 26.20mm | RL-F82 | 6.40mm | 0.22mm | 100 Degree | 30 Meters | |
| 1" | 25mm | 32.70mm | RL-F83 | 8.70mm | 0.22mm | 150 Degree | 30 Meters | |
| 1-1/4" | 32mm | 41.40mm | RL-F84 | 10.50mm | 0.35mm | 180 Degree | 15 Meters | |
| 1-1/2" | 38mm | 47.40mm | RL-F85 | 11.40mm | 0.35mm | 200 Degree | 15 Meters | |
| 2" | 50mm | 59.40mm | RL-F86 | 11.40mm | 0.38mm | 250 Degree | 10 Meters | |
| 2-1/2" | 63mm | 72.10mm | RL-F87 | 14.20mm | 0.45mm | 300 Degree | 10 Meters | |
| 3" | 75mm | 87.90mm | RL-F88 | 14.20mm | 0.45mm | 450 Degree | 5 Meters | |
| 3-1/2" | 83mm | 98.50mm | RL-F89 | 14.20mm | 0.45mm | 500 Degree | 5 Meters | |
| 4" | 100mm | 113.20mm | RL-F90 | 14.20mm | 0.45mm | 600 Degree | 5 Meters | |
Why Choose Ranlic Flexible Conduit
We are sending samples free of charges
All testing and the production in the our factory to assure the quality
When start buying our products,if destination markets growing fastly ranlic
will pay advertisment in customer's market to help our customer publishing
our brand.
