Malleable Iron Fitting Reducer Bush Hot Dip Galvanized 20MM TO 25MM 3/4" TO 1"

This is a physical property of metals and metalloids, or any kind of matter. We call a metal malleable when it can easily be deformed, especially by hammering or rolling, without cracking the metal.

We are manufacturer of Malleable Iron Pipe Fittings and supply high quality Malleable Iron Pipe Fittings in both large and small quantities worldwide and offer you the best prices in the market.

Malleable Iron Pipe Fittings(Forged High Pressure Pipe Fittings)

Our products are famous for the perfect finish, excellent resistance to wear, accurate fit and long trouble-free life.

They can be divided into three standards:

Malleable Iron Fitting Reducer BushMalleable Iron Fitting Reducer BushMalleable Iron Fitting Reducer Bush

American standard:

ANSI maleable pipe fitting
  • Materials: ANSI/ASME A197-79
  • Dimensions:ANSI/ASME B16.3-85
  • Threads: ANSI/ASME B1.20.1

DIN Standard:

  • Materials: DIN1692
  • Dimensions:DIN2950
  • Threads: DIN2999
  • British Standard:
  • Materials: ISO 5922
  • Dimensions: ISO 49
  • Threads: ISO 7/1

Electric Galvanized Malleable Iron Pipe Fittings

  • Standard: American, DIN, British
  • Material: ANSI/ASME A197-79, DIN1692, ISO 5922
  • Dimensions: ANSI/ASME B16.3-85, DiN 2950, ISO 49
  • Threads: ANSI/ASME B 1.20.1, DIN 2999, ISO 7/1
Malleable Cast Iron Pipe Fittings (DIN EN std 150#)

Galvanized Malleable Pipe Fittings

We manufacture over 600 dimension types of fittings (from ¼" to 4″)
that can have black or galvanized surface.

  • Malleable iron pipe fittings with DIN threads, Hot dipped galvanized and black finished.
  • Material: ASTM A197, ASTM A47;
  • Dimensions: ISO 49, DIN EN 10242;
  • Threads: ISO 7/1
  • Size Available: 1/8"-6"

Product Details

Bush - Male to Female Reducing - BSPPF x BSPTM

Malleable cast iron fittings are highly durable and temperature resistant making them ideal for use in air conditioning, plant engineering, gas lines and lubricant pipework.


intermediate pressure rating at temperature between 120°C and 300°C can be obtained by linear interpolation; hot dip galvanised fittings should not be used below -10°C.


BS 143; BS 1256; BS 21; ISO 49; ISO 7/1

Malleable Fittings - Bushes

axwill malleable iron pipe fittings are to BS143/1256, ISO49 and threads (taper male and parallel female) are to BS21, ISO7/1. The fittings are available self-colour (black) or hot dip galvanised finish to BS729 for increased corrosion resistance. Pressure rating is 25 bar at service temperature -25°C to +120°C and 20 bar at 120°C to 300°C.,Crane Fluid Systems straight pipe fittings are available self-colour (black) or galvanised finish, with taper internal and external pipe threads to BS21 and ISO7 for pressure-tight joints. They can be used with BS1387 steel tube for air, gas, steam and water services. Pressure rating is 25 bar at service temperature -20°C to +120°C and 20 bar at 120°C to 300°C.

60.3mm Internal diameter. 20mm Boxes - min 25mm deep, 25mm boxes - min 28mm deep.
Tapped M4 at 50.8mm centres, with tapped hole in base for earthing screw.
Supplied without covers or earthing screws unless ordered.

One way,two way,angle way and four way all available
We have all sizes from 20mm to 50 mm
All the malleable circular box C/W cover and gaskets expect requriement when ordered

RANLIC BS4568/BS31 Mallable Circular Terminal Box
Marking: RANLIC
Material: Malleable Iron
Standard: BS4568/BS31/IMC/RIGID
Size: 20mm to 50mm( bs4568 conduit) 3/4" to 2"(imc rigid conduit)

Used for bs4568 and bs31 class 4 conduit pipe

Hot dip galvanized durable and never rusted,Painting also available

Ranlic brand is engraved on the products, also can make OEM
Material: Malleable Iron
Standard: BS4568:PART 1 1970 BS EN 50086

BS EN 61386
With tapped hold in base for earthing screw,supplied w/o cover and screws unless ordered
Size: 20mm-50mm
K.O.: one way to four way, inspection bend, inpsection elbow and TEE

Characters & Diemension:

RL111-20 Malleable Iron Hot Dip/Painting 20mm GI CONDUIT BS4568 CLASS 4
RL111-25 Malleable Iron Hot Dip/Painting 25mm GI CONDUIT BS4568 CLASS 4
RL111-32 Malleable Iron Hot Dip/Painting 32mm GI CONDUIT BS4568 CLASS 4
RL111-38 Malleable Iron Hot Dip/Painting 40mm GI CONDUIT BS4568 CLASS 4
RL111-50 Malleable Iron Hot Dip/Painting 50mm GI CONDUIT BS4568 CLASS 4

Other Terminal Box(Circular Box) Available

One way box-terminal box. Two way box-Angle box, Two way box-Through box, Three way box-Tee box, four way box-intersection box, branch two way box (U), branch three way box (Y), twin through way box (H) available
Why Choose Ranlic Conduit Item:
1) High quality material ensures a finish conduit and fittings with superior properties
2) Manufactured by perfect molds and professtional engineer
3) Fitted perfectly with fittings(conduits) for the CNC threading machine
4) 10 years export experience to make sure the perfect shipment date and package
5) Always like to listening customers feedback for the conduit arrived to
customer's warehouse to improving our service

RANLIC BS4568/BS31 Malleable Circular Box
to protect conductors in threaded bs4568 class 4 conduit, act as pull and splice boxes, interconnect lengths of conduit, change conduit direction and provide access to conductors for maintenance and future system change.

1. With tapped hole in base for earthing screw.
2. Supplied with covers and fixing screws if required
3. Order 3/4"-2" when using with rigid steel conduit
4. Order 20mm-50mm when using with BS4568 Conduits.
5. BS31 boxes also available in aluminum die casting & finish polishing
6. Box Covers are available 0.80mm to 1.2mm thickness, finish pre-galvanized
Electro-galvanized or Hot dip galvanized

We supplier only the high quality products, most of our Malleable circular box weight according to BS4568 61386 stipulated . two screws of the terminal box always keep same
distence in order when put on the sockets can not use

Wish you have a good day and everything goes well.

Axwill is a professional manufacture of EMT/IMC/RSC Conduit & 90% Normal related accessocires together with prefabrication steel box brackets and conduit junction box,struct channel, threaded rod with 15 years history. And our factory cooperated with many world famous brands. We have Abundant OEM experience serving USA UK UAE upscale market with BSI/UL/ISO9001 certificate.


1. We produce Raw material(Steel Coil ) by ourselves ,we can control the quality strictly
2. Original factory price (we produce steel coil by ourselves, That's why we can keep good quality and competitive price )
3. Fast delivery time(warehouse in Dubai,Qatar)
4. We are Mature supplier in UK, United States, Canada,Middle east ,Singapore ,Malaysia, Panama, Costa Rica,Clombia,Honduras,Dominicana Republic,Trinida&Tobacco ... market .

My friend, Do you have interesting with our struct channel, threaded rod ?If yes please send it to us we calculate a very competitive price for you.We hope to have the opportunity to work together with you in the future.
