Prefab Mud Ring For Steel Outlet Box UL Listed
Electrical Steel Conduit Box Support 3 and 4 Devices Open box mounting bracket
1)Open box support allows for adjustablility of box position between studs
2) Support most North American boxes and/or plaster rings 4" SQ 4-11/16SQ
5"SQ and multi-gang boxes
3) Fits up to 1-1/2" wide studs 16" &24"on center
4) Compatible with rapid ring & adjustable plaster rings
5) Field cut to adjust to non-standard stud spacings
6) Stamped markings at 1/2" 1/4"and 1" increments to allow the installer to easily locate the desited box position
7) You may contact us for pre-fab assemblies
8) Bracket accessories require no tools to install 9) Fllor stand ensures consistent box height and eliminates need to measure for proper install height.
bracket for 16" or 24"stud spacing
1,measure distance between studs
2,cut measurd ruler mark after
3,screw parts together
4,boxes size is 4" or 4-11/16" square
CONSTRUCTION DETAILS: BOX SUPPORT BRACKETS, CAT. NOS. AX7-16, AX7-24 FIG. 1 GENERAL - The basic design, shape and arrangement shall be as illustrated except where variations are specifically described. 1. Bracket - Shaped as shown, Pre-galvanized steel. See following table, FIG., ILL. and dimensions for details. | Cat. Nos. | Minimum Thickness, mm | FIG. No. | ILL. No. | Accessory |
| AX7-16 | 0.80 | 1 | 1 | No |
| AX7-24 | 1.00 | 2 | 2 | No |
Alignment plate can be cut on a mark to make shorter length brackets
Can be used with floor stand
